Product Overview
With its 1.9x base magnification, 384×288 detector and a 19mm F1.0 lens, the HIKMICRO Lynx LH19 3.0 offers a versatile solution for demanding scenarios. It delivers a 13.8° (24. m at 100m) wide field of view and a detection range of up to 900m, making it ideal for hunters and outdoor explorers who need a compact yet powerful device with shutterless imaging technology.
Key Features
• High-sensitivity thermal module with NETD < 15mK
• 19 mm, F1.0 lens with thermal detection range up to 900m
• AI-powered Image Pro 3.0 and Zoom Pro algorithms
• HIKMICRO Shutterless Image System (HSIS)
• 0.49-inch 1920 × 1080 resolution AMOLED display
• Replaceable and rechargeable 18650 battery provides up to 4.5 hours of continuous operation at -20°C
• Lightweight design at 331g, with a pocket–sized build
| SPECIFICATIONS | |
| Thermal Module | |
| Image Sensor | VOx Uncooled Focal Plane Arrays |
| Resolution | 384 × 288 |
| Frame Frequency | 50 Hz |
| Pixel Interval | 17 μm |
| Response Waveband | 8 μm to 14 μm |
| NETD | Less than 35 mK (@25°C),F#=1.0 |
| Focal Length | 35 mm |
| Field of View | 10.66° × 8° (H × V) |
| Aperture | F1.0 |
| Magnification | 2.3 to 18.4 |
| Image Display | |
| Monitor | 0.39 inch, OLED, 1024 × 768 |
| Palettes | Black Hot, White Hot, Red Hot, Fusion |
| FFC (Flat Field Correction) | Mode Auto, Manual, External Correction |
| Digital Zoom | 1x, 2x, 4x, 8x |
| Smart Function | |
| Hot Track | Yes |
| Detection Range | 1235 m |
| System | |
| Storage | Built-in memory module (16 GB) |
| Record Video | Yes |
| Capture Snapshot | Yes |
| Wi-Fi | Yes |
| Standby Mode | Yes |
| Power Supply | |
| Battery Type | Rechargeable Lithium Battery |
| Battery Operating Time | 7 hours continuous running with Wi-Fi hot spot function off (@25 °C) |
| 5.5 hours continuous running with Wi-Fi hot spot function on (@25 °C) | |
| Battery Capacity Display | Yes |
| General | |
| Mounting | UNC 1/4' - 20 |
| Hardware Interface | Type-C USB |
| Power | 5 VDC/2 A |
| Power Consumption | 1.5 W |
| Work Temperature/Humidity | From -30°C to 55°C (-22°F to 131°F); Humidity: 90% or Less |
| Protection Level | IP67 |
| Drop Test | Height 2 m (6.56 feet) |
| Dimension | 201.6 mm × 73.7 mm × 66 mm (7.94" × 2.90" × 2.60") |
| Weight | 500 g (1.10 lb) |
