Guide ApexVision TU1260MS Thermal Scope

The TU MUO 3.0 sets a new benchmark in precision optics, combining advanced thermal and night vision technology into one rugged, all-weather device.

The TU1260MS is powered by the next-generation APEXVISION infrared imaging system and features a powerful 1280 × 1024 @12μm detector with 15mK NETD sensitivity and Hyper-Light enhancement. It delivers unmatched infrared imaging even in the toughest environments. A built-in laser rangefinder offers pinpoint accuracy out to 1500m, giving you confidence at any distance.

Built to endure extreme conditions, the TU MUO is IP68-rated and shock-resistant up to 6,000J, making it the ultimate choice for serious hunters and professionals who demand reliability without compromise.

INCLUDES QUICK  RELEASE SCOPE MOUNT: Torque Settings = <2.5N·m / 22.13 in-lbs
INCLUDES IR TORCH & 30MM BRACKET

Complete ApexVision S1 System Architecture

Guide Sensmart’s next-generation thermal imaging solution that redefines the infrared core of outdoor optics from the ground up. Engineered for any condition, ApexVision delivers ultra-clear visuals with smooth, ghost-free motion, high-fidelity imaging, and razor-sharp detail at long range.



Thermal & Optical, All-Day. All-Weather

The TU Muo 3.0 Series combines thermal imaging and visible light technology with dedicated day, night, and low-light modes, delivering reliable performance in any environment.



Hyper-Light Algorithm, Ultra-Premium Visuals

Powered by next-generation sensors and the Hyper-Light algorithm, it delivers enhanced clarity, reduced noise, and optimized contrast, bringing out finer details with exceptional precision.



2560×2560 Display for Comfortable Viewing

Featuring a 1.03-inch AMOLED display with 2560×2560 resolution, the TU M 3.0 Series delivers crisp, detailed visuals. With 60mm eye relief and AI-enhanced imaging, it ensures a more comfortable viewing experience, even during extended use.



Dual Battery Design, Worry-Free Power

Two built-in batteries, combined with a replaceable external power source, deliver up to 12 hours of continuous use. Hot-swappable standard 18650 batteries allow you to extend runtime even further, keeping you powered in the field.





SPECIFICATIONS

Product Name	Guide TU1260MS Thermal Scope
Laser Rangefinder	1500m
Type-C Power Supply	USB-C (Charge/USB 2.0)
Battery Operating Time	9 Hours
Battery Type	18650 ×2 Battery (Built-in) and 18650 ×1 Battery (External)
Audio Recording	Yes
Standby Mode	-
Hotspot	Yes
Capture Snapshot	-
Record Video	Yes
Working Temperature	-20°C to 50°C
Dimension	450×90×91mm
Weight	1145g
Protection Level	IP68
Image Pro	N/A
HSIS	N/A
Zoom Pro	N/A
Diopter	-5 to +5
Exit Pupil	-
Palettes	IR: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia; Visible: Day, Night, Low-light
Display	1.03'' AMOLED 2560×2560
Magnification	Thermal: 2.3x~36.8x; Digital: 5.1x~81.6x
Field of View (Degrees/m @ 100m)	Thermal: 14.6°×11.7°; Digital: 6.4°×5.1°
Detection Range	Thermal: 3200m/2800yd; Digital: 330m/360yd
NETD	15mK
Response Waveband	8um to 14um
Pixel Interval	12um
Frame Rate	50Hz
Sensor Resolution	Thermal: 1280×1024; Digital: 1920×1080
Lens (Focal Length)	Thermal: 60mm, F0.9; Digital: 35mm, F4.0
